- Light-weight and flexible than TOTAKU SD-F.
- High anti-static performance.
- Inner slipping improves more than TOTAKU SD-F.
- Conform to Notification of Ministry of Health,Labour and Welfare No.201(Except for Heptanes )
- DOP isn't included.
- ※No-suitable for transportation of oily foodstuffs and fluid.
- For transportation of steamed rice
- For transportation of foodstuffs.( powder & granule)
- For transportation of receptacle for foodstuffs.
- For transportation of pellet of receptacle for foodstuffs
| Fluid | Water・hot water、Powder・granule、Food |
|---|---|
| Material | PVC |
| Temperature | -10 ～ 50 |
| Function | ・Conforms to Ministry of Health,Labour and Welfare Notifications ・Low odor ・Having transparency |
| Nominal diameter |
Inside Diameter mm |
Outside Diameter mm |
Pitch mm |
Weight(reference) g/m |
L/coil m |
Allowable pressure(at room temperature) MPa｛kgf/cm2｝ |
Allowable bending radius mm |
|---|---|---|---|---|---|---|---|
| 100｛4｝ | 101.6 | 115.0 | 16.4 | 1980 | 20 | 0.10｛1.0｝ | 430 |
| 125｛5｝ | 125.9 | 141.6 | 22.0 | 2520 | 0.10｛1.0｝ | 500 | |
| 150｛6｝ | 152.4 | 172.0 | 22.0 | 4530 | 0.15｛1.5｝ | 980 |
| Nipple for hoses |
|---|
| Bands & Swaging |
