(mm)
| Nominal diameter | Ａ | Ｂ | Ｃ | Ｄ | Ｅ | P | Ｌ |
|---|---|---|---|---|---|---|---|
| 38 | 44.0 | 38.0 | 38.7 | 47.7 | 35 | 9.0 | 70 |
| 50 | 56.8 | 50.8 | 54.0 | 64.0 | 35 | 10.5 | 70 |
| 65 | 69.5 | 63.5 | 68.0 | 78.0 | 35 | 12.0 | 76 |
| 75 | 82.5 | 76.5 | 78.0 | 88.0 | 40 | 13.5 | 85 |
| 90 | 95.9 | 88.9 | 90.0 | 100.0 | 45 | 13.6 | 95 |
| 100 | 108.6 | 101.6 | 103.5 | 115.5 | 45 | 14.5 | 95 |
| 125 | 134.0 | 127.0 | 127.5 | 140.5 | 45 | 15.5 | 95 |
| 150 | 160.4 | 152.4 | 155.0 | 166.0 | 50 | 19.0 | 113 |
| 200 | 213.2 | 203.2 | 205.0 | 217.0 | 55 | 21.0 | 125 |
| 300 | 314.8 | 304.8 | 304.8 | 318.8 | 60 | 21.0 | 160 |
