- For transporting of foodstuffs
- ※No suitable for transportation of oily foodstuffs or fluid
Conformed to “Food Sanitary Law, Notification of Ministry of Health , Labour and Welfare No.201” (Except for dissolving test on oils and fats and fat-related food, Heptanes). - Less inner resistance enables more transportability.
- High anti-static performance.
- Lightweight, very flexible and superior abrasion resistance.
- Translucent wall enables visual check of the material flow.
- For transportation of plastic pellets (For food packaging's and toys, etc.)
- For transportation of powder & granule of foodstuffs
- For transportation of medicines
- Additionally, for transportation of powder & granule form besides
the food
※Please take a range of 0°C to 50°C as standard allowable temperature, subject to change of allowable pressure depending on use temperature. In case of continuous use, 40°C or less is recommended.
■CAUTIONS
※Please avoid the use and storage over the long period of time in the outdoors.
| Fluid | Water・hot water、Powder・granule、Food、Chemical (including pure water） |
|---|---|
| Material | Non-PVC |
| Temperature | 0 ～ 50 |
| Function | ・Conforms to Ministry of Health,Labour and Welfare Notifications ・High anti-static performance(with no ground wire) ・Excellent medical durability ・Having transparency (translucent) ・Low odor ・Can be incinerated by fire after use ・Excellent abrasion resistance |
| Nominal diameter |
Inside Diameter mm |
Outside Diameter mm |
Pitch mm |
Weight (reference) g/m |
L/coil m |
Allowable pressure (at room temperature) MPa{kgf/cm2｝ |
Allowable bending radius mm |
|---|---|---|---|---|---|---|---|
| 38｛1½｝ | 38.0 | 48.0 | 9.0 | 340 | 50 | 0.10｛1.0｝ | 150 |
| 50｛2｝ | 50.8 | 62.0 | 10.0 | 550 | 195 | ||
| 65｛2½｝ | 63.5 | 76.0 | 14.3 | 695 | 20 | 255 | |
| 75｛3｝ | 76.2 | 92.5 | 15.8 | 950 | 20 | 255 | |
| 100｛4｝ | 101.6 | 120.0 | 18.0 | 1600 | 20 | 450 |
